1985 Ford Bronco/F150/350 Electrical & Vacuum Troubleshooting Manual

Covering the following: Bronco Custom, XLT, Eddie Bauer / F150 Base, Custom, Ranger, XL, XLT, XLT Lariat / F250 Base, XL, XLT, XLT Lariat / F350 Base, XL, XLT, XLT Lariat, Cab & Chassis | Gas & Diesel Engines

Published by the Ford Motor Company

Covering Diagnostic Procedures * Component Testing * Schematics and Routing Diagrams * Fuse and Relay Information * Power Distribution * Vehicle Repair Location Chart * Wiring Diagrams

This manual contains a complete and comprehensive collection of wiring diagrams, schematics, electrical illustrations, vacuum diagrams, and troubleshooting procedures. It is written by Ford specifically for the vehicle(s) listed and is considered to be the most comprehensive collection of electrical and vacuum information on the market. A must for anyone who insists on Genuine OEM quality parts.
11" x 8 1/2" x 1/3". Approx. 162 pages.

Condition

Good usable condition. Covers show some wear and soiling. All pages are in place and straight. Page surfaces are mostly clean.

Topics Include

• Connector Repair Procedures
• Systems Overview
• Wiring Harness Overview
• Ground Distribution
• Fuse and Relay Information
• Charging System
• Power Distribution
• Module Communications Network
• Component Testing
• Connector Views
• Component Location Views
• Component Location Charts
• Vehicle Repair Location Charts
