1988 Ford Mustang Electrical & Vacuum Troubleshooting Manual

All Including Mustang LX & Mustang GT | Published by the Ford Motor Company

Connector Configurations * Harness Locations * Circuits * Relays * Grounds * Vacuum Diagrams * Valve & Sensor Locations * Hose Colors * Vacuum Distribution * Wiring Diagrams

This is the Official Manual of the dealerships, written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams and exploded views. A must for anyone who insists on Genuine OEM quality parts.
11" x 8 1/2" x 1/2". Approx. 225 pages.

Condition

Very good condition. Covers show very little wear. All pages are in place and straight. Page surfaces are clean.

Topics Include

• Connector Repair Procedures
• Systems Overview
• Wiring Harness Overview
• Ground Distribution
• Fuse and Relay Information
• Charging System
• Power Distribution
• Module Communications Network
• Component Testing
• Connector Views
• Component Location Views
• Component Location Charts
• Vehicle Repair Location Charts
