1988 Honda XR600R Factory Service Manual

Published by the Honda Motor Company | *NOTE: This will also cover XR600Rs through at least 1990

Covering Specifications * Maintenance * Testing and Diagnostics * On Bike Repairs * Component Removal * Disassembly * Reassembly * Installation * Schematics * Wiring Diagrams

This is the Official Service Manual that the dealers and shops use, written by Honda specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is incredibly comprehensive with detailed diagrams and exploded views. It is the best money can buy and a must for anyone who insists on Genuine OEM quality parts.
11" x 8.5" x .3". Approx. 225 pages.

Condition

Good to very good condition. Covers show light wear. All pages are in place and straight. Page surfaces are clean.

Table of Contents

• General Information
• Lubrication
• Maintenance
• Fuel System
• Engine Removal/Installation
• Cylinder Head/Valves
• Cylinder/Piston
• Clutch/Kick Starter
• Alternator
• Crankshaft/Balancer
• Transmission
• Front Wheel/Suspension/Steering
• Rear Wheel/Brake/Suspension
• Hydraulic Brake
• Rear Fender/Exhaust Pipe
• Electrical System
• Wiring diagram
• Technical Features
• Troubleshooting
