1989 Chevy C K Pickup Electrical Diagnosis and Wiring Diagrams Manual

1989 Chevrolet C/K Truck Electrical Diagnosis and Wiring Diagrams

C1500 C2500 C3500 K1500 K2500 K3500 | 1/2, 3/4 & 1 Ton C/K Trucks | All Trims Including WT, SS 454, Cheyenne, Scottsdale & Silverado | 4.3L (262Cu. In) V6, 5.0L (305Cu. In.) V8, 5.7L (350Cu. In.) V8, 7.4 (454Cu. In.) V8 Gasoline & 6.2L (379Cu. In.) V8 Diesel Engines

Published by the General Motors Corporation

Electrical Diagnosis & Power Distribution * Harness Routing Views * Circuit Operation * Circuit Diagrams * Connectors * Component Locater Views * Wiring Diagrams

This factory manual is written by GM specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams and exploded views. A must for anyone who insists on Genuine OEM quality parts.
Large format 11" x 17". Approx. 200 pages.

Condition

Good usable condition. Covers show some wear and soiling. All pages are in place and straight. Page surfaces are mostly clean.

Topics Include:

• Harness Routing Views
• Basic Electricity
• Electrical Diagnosis
• Circuit Diagrams
• Circuit Wiring
• Connector Diagnosis Procedures
• Connectors
• Component Locator Views
• Component Locator Index
