1998 Ford Escort ZX2 Coupe Electrical Vacuum & Troubleshooting Manual Original

1998 Ford Escort ZX2 Coupe Electrical & Vacuum Troubleshooting Manual

Escort Coupe Models Only Including Escort ZX2 Cool Coupe & Escort ZX2 Hot Coupe

11" x 8.5" x .4" | Approx. 250 pages | Published by the Ford Motor Company

Connector Configurations * Harness Locations * Circuits * Relays * Grounds * Vacuum Diagrams * Valve & Sensor Locations * Hose Colors * Vacuum Distribution * Wiring Diagrams

This is the Official Manual of the dealerships, written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams and exploded views. A must for anyone who insists on Genuine OEM quality parts.

Condition

Very good condition. Covers show very little wear. All pages are in place and straight. Page surfaces are clean.

Topics Include

• General Information
• Grounds
• Fuse Panel/Circuit Protection
• Charging System
• Power Distribution
• Communication Network
• Wiring Diagrams
• Component Testing
• Connector Faces
• Component Location Views
• Harnessing
• Vehicle Repair Location Codes
