1998 Ford F150 F250 Truck Electrical & Vacuum Troubleshooting Manual Original
- Condition:
- Used
Description
1998 Ford F-150 & F-250 (Under 8500GVW) Electrical & Vacuum Troubleshooting Manual
Covering the F150 Base, XL, XLT & Lariat / F250 Base, XL, XLT, Lariat & Lobo 50th Anniversary | Standard & Extended Cabs | 2x4 & 4x4 | 4.2L V6, 4.9L I6, 4.6L V8 & 5.4L V8 Gasoline & Natural Gas Engines | *NOTE: This Does Not Cover the F250 Super Duty
Published by the Ford Motor Company
Connector Configurations * Harness Locations * Circuits * Relays * Grounds * Vacuum Diagrams * Valve & Sensor Locations * Hose Colors * Vacuum Distribution * Wiring Diagrams
This is the Official Manual of the dealerships, written by Ford specifically for the vehicle(s) listed. This ensures you get the job done right the first time. It is very detailed with good diagrams, photos and exploded views. A must for anyone who insists on Genuine OEM quality parts.
11" x 8 1/2" x 1/2". Approx. 275 pages.
Available Conditions
- Very good condition. Covers show little wear. All pages are in place and straight. Page surfaces are clean.
- Good usable condition. Covers show wear and creasing. All pages are in place and straight. Page surfaces are mostly clean.
Topics Include:
- General Information
- Grounds
- Fuse Panel/Circuit Protection
- Charging System
- Power Distribution
- Communication Network
- Wiring Diagrams
- Component Testing
- Connector Faces
- Component Location Views
- Harnessing
- Vehicle Repair Location Codes
